Description
| Brand | Cooler Master |
|---|---|
| Series | MasterWatt Series |
| Model | MPX-7501-AMAAB-U1 |
| Type | ATX 12V V2.4 |
|---|---|
| Maximum Power | 750W |
| Fans | 1 x 120mm LDB Bearing Fan |
| PFC | Active |
| Main Connector | 24Pin |
| +12V Rails | Single |
| PCI-Express Connector | 4 x 6+2-Pin |
| SATA Power Connector | 9 |
| Modular | Semi-Modular |
| Power Good Signal | 100-500ms |
| Hold-up Time | 16ms at 80% load |
| Efficiency | 85% @ Typical Load |
| Energy-Efficient | 80 PLUS BRONZE Certified |
| Over Voltage Protection | Yes |
| Input Voltage | 100 – 240 V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 10 – 5A |
| Output | +3.3V@22A, +5V@22A, +12@62.5A, -12V@0.3A, +5VSB@3A |
| MTBF | >100,000 Hours |
| Approvals | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
| Dimensions | 5.51″ x 5.91″ x 3.39″ |
| Max PSU Length | 140 mm |
| Weight | 4.47 lbs. |
| Connectors | 1 x MB 24 pin 1 x CPU 12V 4+4Pin 4 x PCI-e 6+2 Pin 9 x SATA 3 x Peripheral 4 Pin 1 x FDD Cable 4 Pin |
|---|---|
| Features | Semi-Fanless up till 15% load – Experience noise-free operation in normal PC loads under 15% output.
Dual Forward and DC-to-DC circuit design – The Dual Forward and DC-to-DC circuit design offers reliability and stability especially significant in +3.3V and +5V output. 5 years warranty – The MasterWatt comes with a 5 year warranty. More Conductive PCI-e Cables – The MasterWatt uses 16AWG cables for PCI-e cables. Less resistance means better efficiency. 80 PLUS Bronze Certified – The 80 PLUS Bronze certification means MasterWatt is independently tested with efficiency of 85%. Durable LDB bearing – Silencio technology combines sealed LDB bearings with quiet fan blades delivering a long lifetime of quiet cooling. |
